SPF5-24A
Product Category:XLR Male Jack (SPM)
Product Details：xlr jack,xlr connector,xlr socket,xlr chassis jackContact us：86-755-83983710
SPF5-24A
Audio Professional XLR Connector
Technical Data
Temperature
-30℃to+80℃
Withstand voltage
1500Vac(50Hz)min
Rated voltage
50Vac
Insertion and Extraction Force
≤20N
Contact Resistance
≤30mΩ
Lifetime
1000 cycles
Insulation Resistance
Initial: ﹥2GΩ
After damp heat test:﹥1GΩ
Specification Drawing
Packaging & Delivery
Packaging Details：poly bag inside export standard carton or can be customized
Port：shanghai/ningbo/shenzhen
Lead Time : 15-20days
MOQ:1000PCS
SPQ:500
Inquire：SPF5-24A
